Viegas {CIH 2.35} Digital Cinema

[CollinViegas]

Some of you may have already seen these photos but I figured I would explain how the room was constructed.

The room itself is 24'11'L x 13'10"W x 7'8"H

The walls are staggered studed Double Drywall w/Green Glue, 1" Knauf acoustic a bit passed halfwall and the rest is batting

The stage is built on top of Acoustik Mat and filled with about 4700lbs of sand all decoupled about 1.5 inches from exterior walls.

The riser is just filled with insulation and behind the screen is treated with 2" knauf acoustik and bass traps in the corners. The inside of the bulk head is also treated aswell to make them bass traps

The carpet is made by mohawk it's called {Highrise Retreat} Color {Ebony Polish} in the picture it looks black on grey but in real life it is black on black

Front speakers and subs are behind the screenwall, the 4 surrounds are in the back columns

Seating is: {Berkline 075 power recline}

Equipment for the room is:
120" 2.35 Acoustic SMX Screen
Sony VPL-VW60 Projector
Panamorph UH380 Anamorphic Lens
Panamorph MTH1 Transport
Klipsch KL-650-THX L/C/R x3
Klipsch KS-525-THX rears and sides x4
Definitive Technology Supercube trinity subwoofers x2
Velodyne SMS-1 Bass Management
Pioneer Elite SC-09TX Receiver
Pioneer Elite DV-79AVi DVD Player
Pioneer Elite BDP-05-FD Bluray Player
Toshiba HD-A1 HD-DVD Player
xbox360
Playstation 3
Nintendo Wii
Monster HTPS7000 Power Center
Monster AVS2000 Voltage Regulator
Pronto Professional TSU9600 Remote
Pronto RFX9600 RF Remote Extender

View From Back Row {Closest picture to the real shade of red in the room}


Looking back at the room from the stage


Walking into the room


Projector with Lens Setup


Equipment Rack


Remote


I will post pictures of the equipment / Media room when it is completed.
Thanks for looking and enjoy
